SPI-WL4 ESP32 WLED Digital Controller with WiFi RF

SPI-WL4 4-Channel ESP32 WLED Digital LED Controller – WiFi + 2.4GHz RF, DC5-24V, 1024 Pixels/Channel

Features;

Wireless Connectivity (WiFi & 2.4 GHz RF Dual): Equipped with the state-of-the-art ESP32 chip, this controller enables connectivity via both WiFi and 2.4 GHz RF technology to provide low latency control of SPI LED strips through mobile applications and compatible MiBoxer RF controllers.
Four Independent Channels Output: Comes with four independent output channels, enabling you to control up to four different SPI LED strips using different colors, light effects, and brightness settings.
High Pixel Capacity for Advanced Effects: The controller’s each output channel has the ability to control up to 1024 pixels.
Multiple Dynamic & Music Lighting Modes: Includes 28 white modes, 80 colorful dynamic effects, and 4 music-responsive modes using built-in microphone or smartphone audio detection for interactive lighting.
Wide Compatibility with SPI LED Chips: Compatible with popular digital LED chipsets including WS2811, WS2812, SK6812, TM1814, APA102, LPD8806, SM16825, USC8904, and many more, making it ideal for digital LED strip projects.

Product Specifications
Product Name	4-Channel ESP32 WLED Digital Controller	Model	SPI-WL4
Input Voltage	DC5V-24V	Output Current	Max 10A
Channels	4 Channel Output	Pixel Capacity	1024 Pixels / Channel
Communication Protocol	WiFi + 2.4GHz RF	RF Control Distance	Up to 30m
Output Signal	SPI (TTL) 800Kbps	Standby Power	0.7W
Compatible LED Types	Single Color / CCT / RGB / RGBW / RGB+CCT	IP Rating	IP20
Working Temperature	-10°C to 40°C	Dimensions	70 × 44 × 17.5 mm
Certification	CE, EMC, LVD, RED	Warranty	5 Years
