OTM-TD96-JA24 Electronic Transformer – 96W 24V – Triac/ELV/MLV Dimmable – UL Listed | 120V AC
Features:
- Advanced Dimming Technology: Supports Triac, ELV, and MLV dimming with a 0-100% dimming range.
- High Efficiency & Low THD: Operates at 88% efficiency with THD < 20%, ensuring stable power output.
- Versatile Installation: Suitable for damp, dry, and wet locations, ideal for LED strips, residential, and commercial lighting.
- Built-in Safety Protections: Includes short-circuit and overload protection, automatically recovering from faults.
- Certified & Durable: UL Listed, Class 2, Class P, Type HL, SELV, and RoHS compliant, backed by a 5-year warranty.
Download Specification Sheet Here
Description
| Product Attributes | |||
|---|---|---|---|
| Model Number | OTM-TD96-JA24 | Rated Power | 96W |
| Rated Voltage | 24V | Rated Current | 4.0A |
| Voltage Tolerance | ±1.5V | Input Voltage | 120V AC |
| Frequency Range | 47-63Hz | Power Factor | 0.94@120V AC |
| Efficiency | 88% @ 120V AC | Total Harmonic Distortion (THD) | <20% @ Max Load |
| AC Current | 0.9A | Leakage Current | <0.5mA @ 120V AC |
| Operating Temperature | -40°C to 60°C | Storage Temperature | -40°C to 90°C |
| Certification | UL Listed, Class 2, Class P, Type HL, SELV, RoHS | ||
| Dimensions | 127 × 82 × 41.8 mm (5 × 3.22 × 1.64 inches) | ||
| Application | LED Strips, LED Tape, LED Modules, Residential & Commercial Lighting | ||
| Protection | Short-circuit & Overload Protection (Auto Recovery) | ||
| Warranty | 5 Years | ||
96W
Wattage
Lumens
50,000
Hours Life
CCT
Color Temperature guide
2700k - 5000k Kelvins
Supper Tech LED CCT (Correlated Color Temperature) represents lighting appearance in spaces.
The warmer colour is beneficial for the residential spaces. And The cooler color is ideal for workspaces for a more focused environment.
True colors lighting
Color Rendering Index
Super Tech LED Offers a high CRI (90+)source to measure the ability to reproduce the natural color of light more vibrantly, and realistically as compared to lower CRI, which enhances environment visibility.
Full Range Dimming
0-10 Dimmable
Super Tech LED makes it easier to adjust the lighting intensity and brightness. Dimming up and down changes the visual appearance to your preference.
Touch of modernity
Sleek Modern Design
Super Tech LED light enhanced lighting effects that illuminate and touches modernity as well as having an elegant round design with plastic hours that is long-lasting.
