12V LED Module – 3 LED 0.72W – IP65 Waterproof – 7000K – Injection Molding | BD-FH3XF-HV |Ideal for Signage & Backlighting
- Energy-Saving Brilliance:
Embrace bright lighting without added expenses! Each module consumes only 0.72W while producing a bright 70 lumens per LED, giving you positive illumination as easy on the budget as on the eyes.
- Built to Last:
Tough enough to handle even the harshest conditions, these lights are crafted with high-grade injection-moulded housing, a durable PC lens, and strong PVC wiring, ensuring they keep shining year after year.
- Weatherproof & Worry-Free:
With an IP65 waterproof rating, these modules laugh off dust, rain, and splashes. Whether indoors or outdoors, they’re ready for anything, making them perfect for signs that need to stay bright in any weather.
- Quick & Easy Setup:
No complicated installations here! Just peel-and-stick with the included double-sided adhesive tape, or secure them firmly using the pre-drilled screw holes. Either way, you’ll have them up and running in minutes.
- Endless Lighting Possibilities:
These LEDs shine for backlighting channel letters and light boxes of any type. Thus, wherever high-impact, reliable illumination is needed for storefronts, advertisements, or commercial displays, these backlighting solutions answer the call.
Download Specification Sheet Here
| Product Attributes | |||
|---|---|---|---|
| Model Number | BD-FH3XF-HV | Module Type | Injection Molding |
| Voltage | DC 12V | Wattage | 0.72W |
| LED Quantity | 3 pcs | Lumens per LED | 70 LM |
| Color Temperature | 7000K | Beam Angle | 160° |
| Warranty | 2 Years | Material | PC Lens, PVC Wire |
| IP Rating | IP65 Waterproof | Size | 66×15×6.5mm |
| Wire Gauge | 20AWG | Mounting | Adhesive + Screw Hole |
| Certifications | CE, RoHS | ||
Wattage
Lumens
Hours Life
CCT
2700k - 5000k Kelvins
Supper Tech LED CCT (Correlated Color Temperature) represents lighting appearance in spaces.
The warmer colour is beneficial for the residential spaces. And The cooler color is ideal for workspaces for a more focused environment.
Color Rendering Index
Super Tech LED Offers a high CRI (90+)source to measure the ability to reproduce the natural color of light more vibrantly, and realistically as compared to lower CRI, which enhances environment visibility.
0-10 Dimmable
Super Tech LED makes it easier to adjust the lighting intensity and brightness. Dimming up and down changes the visual appearance to your preference.
Sleek Modern Design
Super Tech LED light enhanced lighting effects that illuminate and touches modernity as well as having an elegant round design with plastic hours that is long-lasting.
