OTM-TD150-JA24 Electronic Transformer – 150W 24V – Triac/ELV/MLV Dimming – UL Listed | 120V AC
Features:
- Wide Compatibility: Smooth 0-100% dimming is compatible with Triac, ELV and MLV dimmers to provide flexible control of lights.
- High Efficiency Performance: Provides up to 90% efficiency, therefore conserving energy while providing optimal light output.
- Ideal for Large Projects: 20-100% load compatibility makes it perfect for use in residential and commercial projects.
- Comprehensive Protection: Short Circuit and Overload protection as well as Automatic Recovery has been integrated.
- Certification and Reliability: UL, Class P, Type HL and RoHS Certified; back up by 5 years for uses into the future.
Download Specification Sheet Here
Description
| Product Attributes | |||
|---|---|---|---|
| Model Number | OTM-TD150-JA24 | Rated Power | 150W |
| Rated Voltage | 24V | Rated Current | 6.25A |
| Voltage Tolerance | ±1.5V | Input Voltage | 120V AC |
| Frequency Range | 47-63Hz | Power Factor | 0.94@120V AC |
| Efficiency | 88% @ 120V AC | Total Harmonic Distortion (THD) | <20% @ Max Load |
| AC Current | 0.9A | Leakage Current | <0.5mA @ 120V AC |
| Operating Temperature | -40°C to 60°C | Storage Temperature | -40°C to 90°C |
| Certification | UL Listed | ||
| Dimensions | 127 × 82 × 41.8 mm (5 × 3.22 × 1.64 inches) | ||
| Application | LED Strips, LED Tape, LED Modules, Residential & Commercial Lighting | ||
| Protection | Short-circuit & Overload Protection (Auto Recovery) | ||
| Warranty | 5 Years | ||
150W
Wattage
Lumens
50,000
Hours Life
CCT
Color Temperature guide
2700k - 5000k Kelvins
Supper Tech LED CCT (Correlated Color Temperature) represents lighting appearance in spaces.
The warmer colour is beneficial for the residential spaces. And The cooler color is ideal for workspaces for a more focused environment.
True colors lighting
Color Rendering Index
Super Tech LED Offers a high CRI (90+)source to measure the ability to reproduce the natural color of light more vibrantly, and realistically as compared to lower CRI, which enhances environment visibility.
Full Range Dimming
0-10 Dimmable
Super Tech LED makes it easier to adjust the lighting intensity and brightness. Dimming up and down changes the visual appearance to your preference.
Touch of modernity
Sleek Modern Design
Super Tech LED light enhanced lighting effects that illuminate and touches modernity as well as having an elegant round design with plastic hours that is long-lasting.
