10mm 2-Pin Hippo-M MAX LED Strip Connector for SMD COB Mono, Strip-to-Wire and Strip-to-Strip

Features;

  • Wide LED Strip Compatibility: Designed for 10mm SMD and COB mono LED strips, ensuring stable and efficient connections for both residential and commercial lighting installations.

  • Strong Electrical Performance: Supports DC3–48V with a maximum 5.5A current rating, delivering reliable conductivity even under demanding LED strip lighting applications.

  • High-Precision Durable Pins: Built with thick-gauge phosphor bronze pins for maximum durability, maintaining secure strip piercing and long-lasting performance in all environments.

  • Transparent Flame-Retardant Housing: Made from clear polycarbonate with UL94V-0 flame-retardant rating, combining safety and optimal light transmission for better illumination effects.

  • Reusable Versatile Design: Engineered for easy installation and reusability, applicable for both IP20 and IP54/65 LED strips. Certified with CE, RoHS, and REACH.

ASK FOR PRICE

Description
Item NO. MX/2045-X10C-2P Item NO. MX/2045-B10C-2P
Connection Type Strip to Wire Connection Type Strip to Strip Joint
Wire Spec No Wire Wire Spec No Wire
Working Voltage / Current DC3–24V / 5.5A Working Voltage / Current DC3–24V / 5.5A
LED Light Type SMD / COB LED Light Type SMD / COB
LED Strip Width 10mm Pin Quantity 2 Pins
Material Polycarbonate, Copper Working Voltage DC3–48V
Max Current 5.5A (@TA=30℃ PCB=3OZ 20AWG) Wire Gauge 20AWG (OD < 2.0mm)
LED Strip Thickness 0.25–0.35mm Certifications CE, RoHS, REACH
